E-beam welding is a process where a high energy beam of electrons from an electron gun is accelerated and focused using electric and magnetic fields, and shot at two materials to join them. The kinetic energy of the electrons creates very high heat which melts the two materials together (electrons are particles with a very small mass, 9*10-31 kg or 2*10-30 lbs to be exact). The electron beam requires that the system be under vacuum to maintain the speed and focus of the electrons thus preventing beam dissipation or scattering (without vacuum, the electrons would run into other molecules in the atmosphere like nitrogen, oxygen, and water vapor, among others). This is where Televac® vacuum gauging comes in, to make sure that the system is under sufficient vacuum to operate correctly.

Vacuum Gauging Equipment for E-Beam Welding

E-Beam溶接には、AMS2680とAMS2681の2つの関連するAMS規格があります。それぞれ1*10-4Torrと1*10-3Torrの真空度を要求している。これらは航空宇宙仕様であることに注意してください。真空度とシステムの要求精度に応じて、Televac の真空度測定にはいくつかのオプションがあり、重要な違いは以下の通りです。

The first option is an active gauge solution. With an active gauge, the control electronics are attached directly to the physical sensor, then there are optional outputs to show the vacuum level including an analog 0 to 10 V output, RS-485 communications, EthernetIP, or PROFINET communications. The active gauges that would be used for E-Beam welding are an MX2A or MX4A (thermocouple vacuum gauges) for measurement from 1000 Torr down to 1*10-3 Torr and then an MX7B (cold cathode vacuum gauge) for measurement from 1*10-3 Torr and deeper vacuum (as low as 1*10-8 Torr).

2つ目のオプションは、制御電子機器と物理センサーを分離することです。これは、E-Beam溶接機のどこか別の場所にリモートディスプレイが必要な場合や必要な場合に理想的です。このための理想的なソリューションは、1*10-3Torrまでの測定のみが必要な場合はMV2A2Aセンサー、またはMX200に 2A/4A(これも1*10-3Torrまでの大まかな真空測定用)と7Bを組み合わせた中・高真空測定用(1*10-7Torrまでの低真空測定用)があります。どのコントローラ(MV2AまたはMX200)を選択するかによって、アナログ0~5V信号、アナログ0~10V信号、RS-232通信、RS-485通信、またはEthernetIP通信のオプション出力があります。

単位について迷っていますか?そんなことはありません。ここでは、Torrから他の一般的な測定単位への簡単な変換をいくつか紹介します(その他の変換については、単位変換をご覧ください)。

1 Torr = 1.33mbar

1 Torr = 1 mm Hg

1 Torr = 1.33 * 10-1kPa

どの製品を選べばいいのかわからない?この画面の右下にあるウィンドウを使用してチャットするか、+1 215 947 2500に電話するか、[email protected] にメールを送ってください!

Eビーム溶接は、大気中でも行うことができることに注意してください。ビームは大気中の異なる分子/ガスに当たることで散逸するため、溶接部の幅が一般的に広くなり、特定の用途には適していない場合があります。
